BRAND Dispensette S Organic Digital Bottletop Dispenser – 0.5–5 mL, with Recirculation Valve

Brand:BRAND

Division

Dosing volume

Length suction tube

Max. dosing volume

Min. dosing volume

With recirculation valve

Specifications

Compare models
Accuracy
0.5 ± R%
Division
0.02 ml
Dosing volume
0.5 ... 5 ml
Length suction tube
240 mm
Max. dosing volume
5 ml
Min. dosing volume
0.5 ml
Precision
0.1 ≤·VK%
UNSPSC
41121516
With recirculation valve
Yes
Available soon

Product description

The BRAND Dispensette S Organic Digital Bottletop Dispenser is engineered for precise and safe dispensing of organic solvents in laboratory settings. Featuring a digital display, this dispenser offers accurate volume settings ranging from 0.5 to 5 mL, with a graduation of 0.02 mL. It is equipped with a recirculation valve, enhancing safety by preventing hazardous vapors from escaping during operation.

Key Features:

  • Brand: BRAND
  • Volume Range: 0.5–5 mL
  • Graduation: 0.02 mL
  • Accuracy: ±0.5% (±25 µL)
  • Coefficient of Variation: ±0.1% (at 10 mL)
  • Recirculation Valve: Yes, for enhanced safety
  • Autoclavable: Yes, at 121 °C
  • Materials in Contact with Media: Borosilicate glass, Al₂O₃ ceramic, tantalum, ETFE, FEP, PFA, PTFE, and PP
  • Includes: Telescopic filling tube, valve mounting tool, PP thread adapter, and performance certificate

This dispenser is ideal for accurately dispensing organic solvents, including chlorinated and fluorinated hydrocarbons (e.g., trichlorofluoroethane and dichloromethane), acids such as concentrated HCl and HNO₃ (excluding HF), trifluoroacetic acid (TFA), tetrahydrofuran (THF), and peroxides.

Downloads

Accessories

Dosing needles for Dispensette® S

ProductDescriptionForMfr#Part#AvailabilityPrice
Dosing needle 10ml, 105mm valve spring tantalum, w/o back dosing valve
BRAND Dosing Needle 10ml, 105mm Valve Spring Tantalum, without Back Dosing Valve
Ta valve spring, w/o recirculation valveDispensette ® S TA7080246.270 991NTD 1,373
Dosing needle 10ml, 105mm valve spring platinum iridium, with back dosing valve
BRAND Dosing Needle 10ml, 105mm Valve Spring Platinum Iridium, with Back Dosing Valve
Pt/Ir valve spring, w. recirculation valveDispensette ® S TA7081226.270 992NTD 6,971
Dosing needle 25/50/100 ml, 125mm fine tip, w/o back dosing valve for Dispensette® S
BRAND Dosing Needle 25/50/100 ml, 125mm Fine Tip, without Back Dosing Valve for Dispensette S
25/50/100 ml, fine tip, w/o recirculation valveDispensette ® S7080066.270 997NTD 1,589
Dosing needle 1/2/5/10 ml, 108mm fine tip, with back dosing valve for Dispensette® S
BRAND Dosing Needle 1/2/5/10 ml, 108mm Fine Tip, with Back Dosing Valve for Dispensette S
1/2/5/10 ml, fine tip, w. recirculation valveDispensette ® S7081026.270 999NTD 5,671
Dosing needle 5/10 ml, 108mm Standard, w/o back dosing valve for Dispensette® S
BRAND Dosing Needle 5/10 ml, 108mm Standard, without Back Dosing Valve for Dispensette S
5/10 ml, standard, w/o recirculation valveDispensette ® S7080056.270 996NTD 1,228
Dosing needle 5/10 ml, 108mm Standard, with back dosing valve for Dispensette® S
BRAND Dosing Needle 5/10 ml, 108mm Standard, with Back Dosing Valve for Dispensette S
5/10 ml, standard, w. recirculation valveDispensette ® S7081046.272 000NTD 5,599
Dosing needle 25/50/100 ml, 125mm Standard, w/o back dosing valve for Dispensette® S
BRAND Dosing Needle 25/50/100 ml, 125mm Standard, without Back Dosing Valve for Dispensette S
25/50/100 ml, standard, w/o recirculation valveDispensette ® S7080086.270 998NTD 1,409
Dosing needle 25/50/100 ml, 125mm fine tip, w/o back dosing valve for Dispensette® S Organic
BRAND Dosing Needle 25/50/100 ml, 125mm Fine Tip, without Back Dosing Valve for Dispensette S Organic
25/50/100 ml, fine tip, w/o recirculation valveDispensette ® S organic7080166.272 004NTD 1,589
Dosing needle 5/10 ml, 108mm Standard, w/o back dosing valve for Dispensette® S Organic
BRAND Dosing Needle 5/10 ml, 108mm Standard, without Back Dosing Valve for Dispensette S Organic
5/10 ml, standard, w/o recirculation valveDispensette ® S organic7080146.272 003NTD 1,228
Dosing needle 25/50/100 ml, 125mm fine tip, with back dosing valve for Dispensette® S
BRAND Dosing Needle 25/50/100 ml, 125mm Fine Tip, with Back Dosing Valve for Dispensette S
25/50/100 ml, fine tip, w. recirculation valveDispensette ® S7081066.272 001NTD 5,888
Dosing needle 5/10 ml, 108mm fine tip, w/o back dosing valve for Dispensette® S organic
BRAND Dosing Needle 5/10 ml, 108mm Fine Tip, without Back Dosing Valve for Dispensette S Organic
5/10 ml, fine tip, w/o recirculation valve forDispensette ® S organic7080126.272 002NTD 1,336
Dosing needle 5/10 ml, 108mm fine tip, with back dosing valve for Dispensette® S Organic
BRAND Dosing Needle 5/10 ml, 108mm Fine Tip, with Back Dosing Valve for Dispensette S Organic
5/10 ml, fine tip, w. recirculation valveDispensette ® S organic7081126.272 006NTD 5,996
Dosing needle 25/50/100 ml, 125mm fine tip, with back dosing valve for Dispensette® S Organic
BRAND Dosing Needle 25/50/100 ml, 125mm Fine Tip, with Back Dosing Valve for Dispensette S Organic
25/50/100 ml, fine tip, w. recirculation valveDispensette ® S organic7081166.272 007NTD 6,213
Dosing needle 1/2/5/10 ml, 108mm fine tip, w/o back dosing valve for Dispensette® S
BRAND Dosing Needle 1/2/5/10 ml, 108mm Fine Tip, without Back Dosing Valve for Dispensette S
1/2/5/10 ml, fine tip, w/o recirculation valveDispensette ® S7080026.270 995NTD 1,336
Dosing needle 10ml, 105mm valve spring tantalum, with back dosing valve
BRAND Dosing Needle 10ml, 105mm, Valve Spring Tantalum, with Back Dosing Valve
Ta valve spring, w. recirculation valveDispensette ® S TA7081246.270 993NTD 6,971
Dosing needle 10ml, 105mm valve spring platinum iridium, w/o back dosing valve
BRAND Dosing Needle 10ml, 105mm Valve Spring Platinum Iridium, without Back Dosing Valve
Pt/Ir valve spring, w/o recirculation valveDispensette ® S TA7080226.270 990NTD 1,373
Dosing needle 25/50/100 ml, 125mm Standard, w/o back dosing valve for Dispensette® S organic
BRAND Dosing Needle 25/50/100 ml, 125mm Standard, without Back Dosing Valve for Dispensette S Organic
25/50/100 ml, standard, w/o recirculation valveDispensette ® S organic7080196.272 005NTD 1,409
Discharge tube w. recirc. valve for Dispensette® S Organic 5-10ml, standard, 105mm
BRAND Discharge Tube with Recirculation Valve for Dispensette S Organic 5–10 ml, Standard, 105 mm
5/10 ml, standard, w. recirculation valveDispensette ® S Organic7081147.643 282NTD 5,888
Discharge tube w. recirc. valve for Dispensette® S Organic 25-100ml, standard, 135mm
BRAND Discharge Tube with Recirculation Valve for Dispensette S Organic 25–100 ml, Standard, 135 mm
25/50/100 ml, standard, w.recirculation valveDispensette ® S Organic7081197.643 322NTD 6,032
Dosing needle 25/50/100 ml, 135mm standard with back dosing valve for Dispensette® S
BRAND Dosing Needle 25/50/100mL, 135mm Standard, with Back Dosing Valve for Dispensette S
25/50/100 ml, standard, w. recirculation valveDispensette ® S7081096.290 121NTD 5,743

Filling valves for Dispensette® S/S Organic

ProductDescriptionForMfr#Part#AvailabilityPrice
Suction valve for Dispensette S/S Organic 1, 2, 5, 10ml
BRAND Suction Valve for Dispensette S/S Organic 1, 2, 5, 10 ml
For 1/2/5/10 ml, with oliveDispensette ® S/S Organic67346.285 394In stockNTD 1,770
Suction valve for Dispensette S/S Organic 25, 50ml
BRAND Suction Valve for Dispensette SS Organic, 25-50ml
F25/50/100 ml, with oliveDispensette ® S/S Organic67356.283 045NTD 2,095

Compare similar models

Exchange Dispensette® S Organic, Digital 0,5 - 5 ml, with recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottletop Dispenser – 0.5–5 mL, with Recirculation Valve

Manufacturer P/N

AT4630331

Part Number

4.662 255

Manufacturer

BRAND

Division

0.02 ml

Exchange Dispensette® S Organic, Digital 5 - 50 ml, with recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottle-Top Dispenser – 5–50 mL, with Recirculation Valve

Manufacturer P/N

AT4630361

Part Number

4.662 256

Manufacturer

BRAND

Division

0.2 ml

Exchange Dispensette® S Organic, Digital 1 - 10 ml, with recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottle-Top Dispenser (1–10 mL), with Recirculation Valve

Manufacturer P/N

AT4630341

Part Number

6.289 458

Manufacturer

BRAND

Division

0.05 ml

Exchange Dispensette® S Organic, Digital 5 - 50 ml, without recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottle-Top Dispenser (5–50 mL), without Recirculation Valve

Manufacturer P/N

AT4630360

Part Number

7.646 013

Manufacturer

BRAND

Division

0.2 ml

Exchange Dispensette® S Organic, Digital 1 - 10 ml, without recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottle-Top Dispenser (1–10 mL), without Recirculation Valve

Manufacturer P/N

AT4630340

Part Number

6.269 455

Manufacturer

BRAND

Division

0.05 ml

Exchange Dispensette® S Organic, Digital 2,5 - 25 ml, with recirculation valve
Available soon
BRAND Dispensette S Organic Digital Bottle-Top Dispenser (2.5–25 mL), with Recirculation Valve

Manufacturer P/N

AT4630351

Part Number

6.273 060

Manufacturer

BRAND

Division

0.1 ml
