Xylem WTW OxiTop-IDS AN12 Respirometric Measuring System for Anaerobic Operation, 12 Measuring Points, 12 Sample Bottles MF45/250

The Xylem WTW OxiTop®-IDS AN12 is a high-capacity respirometric measuring system designed for precise anaerobic degradability testing in environmental and biological samples. It features 12 individual measuring points equipped with OxiTop®-IDS/B measuring heads and MF45/250 sample bottles (250 mL), enabling accurate assessment of biogas yield and anaerobic respiration in compliance with VDI 4630 standards. This system is ideal for laboratories studying fermentability and methane production in biological waste or sludge.

Key Features:

• Brand: Xylem WTW
• Model: OxiTop®-IDS AN12
• Application: Measurement of anaerobic degradability and biogas yield in environmental and biological samples
• Compliance: Conforms to VDI 4630 standards for biogas plant testing
• Pressure Range: Extended measurement range up to 1500 hPa with pressure range excess warning
• Head Design: Corrosion-proof head suitable for H₂S-containing samples
• Sample Bottles: 12 × MF45/250 (250 mL) bottles, each with dual connections for anaerobic setups
• Connectivity: Wireless operation using OxiTop®-IDS/B measuring heads (Bluetooth-enabled)
• Use Case: Ideal for testing anaerobic degradation, sludge activity, and methane yield

Scope of Supply:

• 12 × OxiTop®-IDS/B measuring heads
• 12 × sample bottles MF45/250 (250 mL)
• Nitrification inhibitor
• 12 × magnetic stirring bars
• 1 × stirring bar retriever
• 1 × stirring platform IS-12

Note:

• Please order CO₂ absorber NHP 600 (9.303 403) separately.
• The IDS multi-parameter measuring instruments Multi 3620 IDS Set WL or Multi 3630 IDS Set WL are required and must be ordered separately.

The Xylem WTW OxiTop®-IDS AN12 provides a safe, efficient, and scalable solution for anaerobic testing, ensuring reliable results and ease of operation across 12 synchronized measuring channels.
