Representative image only
Vacuum pump VACSTAR lite Advanced Solution
Sold by: LabFriend Taiwan
Available Soon
Part #: 4.714 171Manufacturer #: 0010014498
Estimated shipping time:Contact us via live chat or via contact us page
Product overview
Scope of supply: Diaphragm vacuum pump VACSTAR lite, vacuum controller VC 10 pro, stand rod
Product Specifications
- HS Code #84141089
- Connection pressure sideDN 8
- Connection suction sideDN 8
- Depth280 mm
- Dimensions (WxDxH)115 x 280 x 445 mm
- Flow rate1 m³/h
- Power supply frequency50/60 Hz
- Height445 mm
- IP codeIP 20
- Max. permitted ambient temp.40 °C
- Max. voltage240 V
- Min. permitted ambient temperature5 °C
- Min. voltage100 V
- No. of stages2
- Noise level54 db(A)
- Power supply100 ... 240 V, 50/60 Hz
- Rated capacity144 W
- TypeVACSTAR lite Advanced Solution
- Type of auxiliary energyMains connection
- Ultimate vacuum9 mbar
- UNSPSC40151502
- Weight10 kg
- Width115 mm
