MOTIC Microscope RED100 Monocular Lens Tube, 45° Viewing Angle, WF10X/18mm, Power Supply 100V-240V, VDE Plug
Representative image only

MOTIC Microscope RED100 Monocular Lens Tube, 45° Viewing Angle, WF10X/18mm, Power Supply 100V-240V, VDE Plug

Sold by: LabFriend Taiwan
Available Soon
Part #: 6.327 672Manufacturer #: 1200100402982
Estimated shipping time:Contact us via live chat or via contact us page

NTD 428,383

Product overview

The MOTIC Microscope RED100 is designed for clear and comfortable viewing with its monocular lens tube inclined at a 45° angle. This model features wide-field oculars (WF10X/18mm) for enhanced clarity and a large field of view. It operates on a versatile power supply (100V-240V) with a VDE plug, ensuring compatibility in various regions. Ideal for educational, industrial, and research environments, the MOTIC RED100 provides reliable performance and ergonomic design for extended use.

Key Features:

  • Brand: MOTIC
  • Monocular head 45°, 360° rotating
  • Wide-field oculars WF10X/18mm for sharp, clear images
  • Reversed triple revolving nosepiece
  • Separate coarse and fine focusing system
  • Gliding stage with one-touch sample clips
  • 0.65 N.A. condenser with iris diaphragm
  • Power supply compatible with 100V-240V input and VDE plug
  • Suitable for laboratory, industrial, and educational applications
  • Sold individually

Scope of Supply

  • Microscope
  • Dust cover
  • Charger
  • Rechargeable batteries

Note: Please order fluorescence filter sets separately.

The MOTIC Microscope RED100 offers great optical performance, convenience, and adaptability, making it an essential tool for professionals and students alike.

Product Specifications
  • HS Code #90118000
  • CondenserAbbe N.A. 0,90/0,13
  • Depth550 mm
  • Depth stage170 mm
  • Dimensions (WxDxH)242 x 550 x 435 mm
  • Height435 mm
  • Inclination angle tube30°
  • Interpupillary distance50 ... 75 mm
  • Magnification eyepieces10x/22 mm
  • Magnification objectives4x, 10x, 40x, 100x
  • Max. interpupillary distance75 mm
  • Max. voltage240 V
  • Min. interpupillary distance50 mm
  • Min. voltage100 V
  • Plug typeEU
  • Power supply100 ... 240 V
  • Revolving nosepiece6-fold
  • Stage (WxD)180 x 170 mm
  • TubeTrinocular
  • TypeBA410E
  • Type of auxiliary energyMains connection
  • Type of illuminationIncident/transmitted light
  • Weight14.2 kg
  • Width242 mm
  • Width stage180 mm
